选购配件
 QM2-2P |
Dual M.2 22110/2280 PCIe (Gen2 x4) SSD expansion card Dimension (L × W × H): 159.85 × 90.30 × 20.60 (mm) Note: Please check the M.2 SSD compatibility list and QM2 Installation Guide |
QM2-2S |
Dual M.2 22110/2280 SATA SSD expansion card Dimension (L × W × H): 159.85 × 90.30 × 20.60 (mm) |
 QM2-2S10G1T |
Dual M.2 2280 SATA SSD & single-port 10GbE expansion card Dimension (L × W × H): 159.85 × 90.30 × 20.60 (mm) |
 LAN-10G1TA |
Single-port (10Gbase-T) 10GbE network expansion card, PCIe Gen2 x4 Dimension (L × W × H): 25.00 × 16.00 × 5.00 (cm) Weight: 1.00 (kg) |
 LAN-10G2SF-MLX |
Dual-port 10GbE SFP+ network expansion card Dimension (L × W × H): 260.00 × 150.00 × 58.00 (mm) Weight: 0.42 (g) |
 LAN-10G2T-X550 |
DUAL-PORT 10GBASE-T NETWORK EXPANSION CARD Dimension (L × W × H): 260.00 × 150.00 × 58.00 (mm) Weight: 0.42 (g) |
 LAN-1G2T-I210 |
Dual-port Gigabit Network Expansion Card Dimension (L × W × H): 195.00 × 120.00 × 32.00 (mm) Weight: 0.20 (g) |
 RAM-2GDR3L-SO-1600 |
DDR type: DDRⅢL(204 PIN) Capacity: 2GB Spec: SAMSUNG 256M X 8 Manufacturer: TRANSCEND Frequency: 1600 Form(PIN): 204PIN Manufacturer P/N: TS256MSK64W6N SAMSUNG Power Supply: 1.35V Temperature: 0℃~85℃ Environmental Regulation: RoHS Note: Make sure all DIMMs meet the requirements for your NAS model (the information listed in product specifications). |
RAM-2GDR3LA0-SO-1866 |
DDR type: DDRⅢL(204 PIN) Capacity: 2GB Spec: 256M X 16 Manufacturer: ADATA Frequency: DDR3-1866 Form(PIN): 204PIN Manufacturer P/N: ADDS186622G13-BSSE Power Supply: 1.35V Dram Organization: 256M*64 Temperature: 0℃~85℃ Environmental Regulation: RoHS Note: Make sure all DIMMs meet the requirements for your NAS model (the information listed in product specifications). |
RAM-4GDR3L-SO-1600 |
DDR type: DDRⅢL(204 PIN) Capacity: 4GB Spec: SAMSUNG 512M X 8 Manufacturer: TRANSCEND Frequency: 1600 Form(PIN): 204PIN Manufacturer P/N: TS512MSK64W6H SAMSUNG Power Supply: 1.35V Temperature: 0℃~85℃ Environmental Regulation: RoHS Note: Make sure all DIMMs meet the requirements for your NAS model (the information listed in product specifications). |
RAM-4GDR3LA0-SO-1866 |
DDR type: DDRⅢL(204 PIN) Capacity: 4GB Spec: MICRON P-DIE 512M X 8 Manufacturer: ADATA Frequency: DDR3-1866 Form(PIN): 204PIN Manufacturer P/N: ADDS1866W4G13-BMIP Power Supply: 1.35V Dram Organization: 512M*64 Temperature: 0℃~85℃ Environmental Regulation: RoHS Note: Make sure all DIMMs meet the requirements for your NAS model (the information listed in product specifications). |
 RAIL-B02 |
Rail kit for rackmount models Note: This rail kit is designed for racks with 25-inch mounting depth. You may need to reserve some space when installing and adjusting the rail kit for racks with 18-inch mounting depth. For installation details, please see https://shop.qnap.com/image/cache/data/QNAP/Rail%20kit/Screen%20Shot%202018-07-30%20at%2012.12.55%20PM-500x500.jpg |
 CAB-DAC15M-SFPP-DEC02 |
1.5M SFP+ 10GbE DIRECT ATTACH CABLE Note: This 10GbE SFP+ network cable is designed for NAS models with an integrated 10GbE SFP+ LAN port or a 10GbE SFP+ network card. |
 CAB-DAC30M-SFPP-DEC02 |
3.0M SFP+ 10GbE DIRECT ATTACH CABLE Note: This 10GbE SFP+ network cable is designed for NAS models with an integrated 10GbE SFP+ LAN port or a 10GbE SFP+ network card. |
CAB-DAC50M-SFPP-DEC02 |
5.0M SFP+ 10GbE DIRECT ATTACH CABLE Note: This 10GbE SFP+ network cable is designed for NAS models with an integrated 10GbE SFP+ LAN port or a 10GbE SFP+ network card. |
 TRX-10GSFP-SR-MLX |
TRX-10GSFP-SR-MLX |
 QXG-10G1T |
Single-port (10Gbase-T) 10GbE network expansion card, PCIe Gen3 x4 Dimension (L × W × H): 18.00 × 11.00 × 5.50 (cm) Weight: 1.00 (kg) |
| 处理器 | Intel Apollo Lake J3455 四核心 1.5GHz |
| 标准系统内存 | 8 GB DDR3L (2 x 4 GB) |
| 最大可扩展内存 | 8GB |
| 内存插槽数 | SODIMM x 2 |
| 闪存 | 4GB eMMC |
| PCIe 扩展槽 | 1 x PCIe gen 2 x 2 插槽 |
| 支持硬盘数量 | 8 |
| 支持硬盘类型 | 热抽换式 SATA 6Gb/s, 3Gb/s HDD or SSD |
| USB 端口 | 4 x USB 3.0 (背面) |
| Gigabit 以太网络端口 | 4 x GbE |
| HDMI 输出埠 | 1 x HDMI 1.4b |
| LED 指示灯 | 状态、硬盘、USB、网络 |
| 按钮 | 电源、系统重置按钮 |
| 系统警示 | 系统警报 |
| 机型 | 2U 机架型 |
| 尺寸 (高 x 宽 x 深) | 89 x 482 x 534 mm 3.5 x 18.98 x 21.02 inch |
| 重量 | 净重: 11.25 kg (24.80 lbs) 毛重: 14.88 kg (32.80 lbs) |
| 耗电量 (瓦) | 硬盘休眠：40.5W 一般运作：63.3W |
| 噪音值 | 运行中：31.6 dB(A) |
| 工作温度 & 相对湿度 | 0-40˚C 0~95% R.H. |
| 电源 | 250W (x2), 100-240V AC |
| 风扇 | 2 x 70mm, 12V DC |
警告：使用不受支持的模块可能导致性能下降、引发错误或使操作系统无法启动。
* 噪音值测试环境：
参考标准: ISO 7779 ; 依 Bay 数装载最多数量硬盘 ; 以 Bystander Position 测量 ; 取机器运行中前方一米处平均数据
设计及规格若有变更，恕不另行通知。
